Primary Treatment | Sedimentation
CSED SU Circular Sedimentation
Suction Type
- Modular bridge design based on 2S profile structure
- Bottom scraper with adjustable multiple suction lifting tubes for sludge removal
- Each suction lifting tube is individually adjustable
- Sludge collection channel under the bridge with hydrostatic center discharge
- Floating sludge collector and skimmer to remove floating sludge “Collector Skimmer” unit option is available. The skimmer unit’s pivoting design allows optimum adjustment for floated sludge removal and comes with an installed sludge discharge pump
- Automatic control for floated sludge skimming via SSLM (Surface Sludge Level Measurement) for automatic optimal removal of floated sludge
- For retrofit, upgrade or special applications it is possible to “custom design” the CSED Sedimentation to fit with existing concrete tanks and structures
CSED SH Circular Sedimentation
Shield Type
- Modular bridge design based on 2S profile structure
- Sturdy design bottom scraper with large scraping shields
- Different material combinations available such as stainless steel, mild steel – painted or epoxy coated or hot dip galvanized
- Optional scraper lifting device bottom for inspection and maintenance during operation
- Modern 3D Design allows fast economic customizing and individual design if needed
- Floating sludge collector and skimmer to remove floating sludge “Collector Skimmer” unit option is available. The skimmer unit’s pivoting design allows optimum adjustment for floated sludge removal and comes with an installed sludge discharge pump
- Automatic control for floated sludge skimming via SSLM (Surface Sludge Level Measurement) for automatic optimal removal of floated sludge
- Bottom scraper lifting device allows safe lifting, inspection and maintenance of bottom scrapers during operation
